Description
EngineCylinder displacement 852 см³ Cylinders 2 Engine cooling Air Engine lubrication type Full pressure Engine name FX Series Horsepower 18.3 kW Motor/engine manufacturer Kawasaki Transmission manufacturer Parker Transmission steps forward Infinite Transmission steps reverse Infinite Transmission type Pump/Wheel motor CapacityBlade-tip speed 18500 m/s Net power at preset rpm 3600 rpm Power output 18.3 kW Power rating 18270 W Productivity 14973.4 m²/h Speed Forward, min-max 0 km/h-17.7 Speed Reverse, min-max 0 km/h-9.7 DimensionsArticle gross weight 587402 g Article net weight 517095 g Base machine, length 145 cm Base machine, height 122 cm Base machine, width 119 cm Base machine, width (chute down) 157.5 cm Base machine, width (chute up) 127 cm Cutting Height, min-max 25-127 mm Cutting height steps 14 Cutting width 122 cm Cutting width, min-max 122-122 cm Deck thickness 4.76 mm Weight 517.1 kg Wheelbase 106.7 cm LubricantsEngine lubrication type Full pressure Fuel tank location Side (Single) Fuel tank volume (with reserve) 26.5 l Fuel type, min (Europe) 87 Octane Fuel type, min 87 octane Oil capacity 2.4 l Oil cooler No Oil filter Yes Oil type Synthetic Power/fuel type Gasoline
|
Equipment12V outlet No Air filter type Dual element canister filter Anti-scalp wheels 3 Armrests No Blade brake clutch (BBC) Yes Blade engagement Electric clutch Blade type High-Lift blade Blades 3 pcs Collector Available as accessory Cup holder Yes Cutting deck type 7-gauge fabricated Cutting methods Collect/Mulch/Side discharge Deck lifting system Manual, hand operated Deck Wash Port No Deflector Included Drive method Lever-operated Drive system Rear wheel drive Drive wheels Rear Electric start Yes Fan-cooled pumps Yes Greasable mandrels Yes Handlebar-mounted gear selection No Headlights No Hinged armrests No Hour meter type Yes Hydraulic equipment lift No Nose roller Yes Parking brake, type Drum Pivoting rear axle No Powder-coated cutting deck Yes Throttle control Yes Water hose connection No PackagingPackaging height 1295 mm Packaging length 1689 mm Packaging volume 3416.49 dm³ Packaging width 1562 mm Quantity in Master pack 1
|
